Optional Chuck |
Dual Head Chuck |
Housing |
Metal Sheet |
Scale |
145 PSI, 10 Bar, 1,000 kPa |
Accuracy |
+/- 0.3 PSI @ 25 - 75PSI |
Operation |
Auto inflate, deflate |
Supply Pressure Max. |
152 PSI |
Inlet Size |
1/4" NPT / BSP female |
Hose Length |
33 ft (10 M) Recoiled Hose |
Advised Application |
Gas Station, Industrial, Workshops |
Supply Voltage |
AC 110 - 240V(50 - 60Hz), or DC 12V |
Wattage |
10 W max. |
Working Temperature |
-10 ~ +50℃ |
Humidity Range |
Up to 95% RH non condensing |
Inflation Flow |
2,000 L/min @ 182 PSI |
IP Rate |
IP44 |
Dimension |
190 x 150 x 70 mm |
Weight |
4.5 kgs |
